Грохот Metso Lokotrack ST 2.3

Machine description :

Lokotrack® ST2.3™ mobile scalping screen is suitable for heavy duty scalping, fine screening and recycling. It is the most compact mobile screener with wide screen and aggressive stroke. Lokotrack® ST2.3™ mobile screener can be used as standalone unit or as part of multi-stage crushing and screening process. ST2.3™ can be easily transported in one piece between sites. The set-up is quick and easy with hydraulic functions and visual indicators.

Lokotrack® ST2.3™ mobile scalping screen's technical specifications

MODEL

LOKOTRACK® ST2.3™

Screen size 3,000 x 1,520 mm (10’ x 5’)

Screening area

4.6 m2 (49 ft2)

Screening working angle 13-23°

Decks 2

Feed hopper 5 m³ (6,5 yd³)

e-Power -

Engine CAT®, 55 kW (74 hp) Stage V

Transport dimensions

Weight 17,000 kg (37,500 lbs)

Width 2,250 mm (7' 6")

Height 2,850 mm (9' 4")

Length 11,800 mm (38')

https://www.youtube.com/watch?v=NHPtJijaI8g

More information

Please contact Martti Hunt (+358404834737, martti@kbauto.fi) for more information
