Новый Гусеничный кран BG LIFT CWE 315

Standard painting: Arms and crane column in yellow RAL 1007, black jacks (color not customizable) Carriage black RAL 9005, stabilizer jacks black RAL 9005.

Reference standard: EN12999.

Electric motor: three-phase 15 kW-400V-50 Hz with variable flow pump + Inverter.

Jib: 4S articulated with n. 4 hydraulic extensions complete with controls and conduits for pipes.

Quick coupling: Quick-faster for crane-jib connection.

Winch: 1900 kg direct pull with pulleys at the tip of the crane with overload control and control.

Pull pulleys: double, 6th base crane extension.

Pull pulleys: in the fourth, 6th extension of the basic crane.

Pull pulleys: at the tip of the Jib 4S.

First extension: manual after 6th extension.

First extension: manual for Jib (NO CE).

N. 2 controls: at the tip of the Jib with exchange solenoid valves and tube collector (not compatible with the operator's basket).

Hook support: lowered adjustable for basic crane capacity Kg 10000.

Special support: shaped for suction cup manipulator for basic crane, max. 7000 Kg (not suitable for lifting with hook).

No. 2 arms: articulated with connecting rods and forks No. 6 hydraulic extensions Heat exchanger.

Rotation: continuous with fifth wheel and hydraulic and electric rotating joint.

Remote control: 8 functions Steady with color LCD display.

Remote assistance telematics unit: RACE - Activation fee excluded

N ° 4 led headlights: (2 front 2 rear) on the wagon

N ° 2 led lights: on the crane arm

Supports for stabilizer plates: 500 mm

Overshoes: covered with vulcanized non-marking rubber

Body: 6mm thick stainless steel with large aluminum lid

Crane arms and column painting: different from yellow 1007, in RAL color range

Carriage painting: different from black, in RAL color range

Single-seat operator basket: without rotation

Two-seater operator basket: without rotation

Two-seater operator basket: with manual rotation

Safety devices: CE approved basket

Oil: Biodegradable
