DONAT Самосвальный полуприцеп

This tipper is ready on stock. Available for immediate dispatch.

The best components available in the market were used during manufacturing.

AXLES AND SUSPENSION: 3 AXLES EACH HAS 9 TON LOADING CAPACITY, AIR SUSPENSION, DRUM BRAKE. AXLES ARE CERTIFIED BY TÜV GERMANY.

BRAKE SYSTEM:

DOUBLE LINE AIR BRAKE SYSTEM. IN ACCORDANCE TO 71/320 EWG REGULATIONS, (WABCO) TEBS TRAILER ELECTRONIC BRAKE SYSTEM.

TIRES: 385 / 65 R 22, 5 – 6 PCS – BRIGESTONE – 11,75 - 22,5 STEEL RIMS.

CHASSIS:

TWO LONGITUDINAL CHASSIS DESIGNED WITH 5 MM ST 52 A1 QUALITY SHEET AND 120X12 I BEAM STEEL BY “GAS APPLIED WELDING METHOD” AND CROSS MEMBERS.

KING-PIN:

2 ” REMOVABLE KING PIN IN ACCORDANCE TO 94 / 20 EC REGULATIONS.

LANDING LEGS:

FRONT LEGS ARE MECHANIC LIFTER, 24 TONES LIFTING CAPACITY.

BODY:

4-5 MM THICKNESS HARDOX/RAEX STEEL, DESIGNED FOR OPTIMAL PRODUCT FLOW.

RAEX STEEL MADE IN SWEDEN by SSAB Corp.

HYDRAULIC LIFT: TURKISH BRAND, 5 GRADE TELESCOPIC HYDRAULIC CYLINDER C GOLD SERIES.

REAR DOOR: AUTO TAIL DOOR

ELECTRIC SYSTEM: ASPOCK AUSTRIA - 24 VOLT ELECTRIC SYSTEM, ELECTRICAL EQUIPMENT IN ACCORDANCE TO 76/756 EEC REGULATIONS, IN CONFORMITY WITH ISO 12098, HAVING 15 POLES OR 2X7 POLES CONNECTED TO THE VEHICLE’S FRONT PANEL.

PAINT: AFTER SAND-BLASTING, DOUBLE LINE EPOXY COATING AND DOUBLE LINE PAINT IN BLUE COLOR.

ACCESSORIES: WHEEL CHOCKS X 2 PCS / FIRE EXTINGUISHER BOX / SIDE PROTECTION / WATER TANK / TOOL BOX / OIL TANK FOR TIPPING CYLINDER / LADDER X 2 PCS

All needed homologation certificates for import and registration of vehicle will be provided.

For more information please contact Donat Trailer.
